Vices And Clamping Tools

Products Of Any Type/Dimension Can Be Manufactured As Per Requirements; Customers’ Designs And Logos Are Welcome.

We are the Manufacturers & exporters of a wide variety of "Vices & Clamping Tools".

Some of the standard Vices & Clamping Tools are:

  Art  551

    UNGRIP DRILL PRESS VICE



  Art  552

    TOOL MAKERS TILLING VICE



  Art  553

    PRECISION GRINDING VICE



  Art  554

    MACHINIST JACK


  Art  555

    BEARING PULLER THREE LEGS





UNGRIP DRILL PRESS VICE

Article  551



Rugged Drill Press Vise with removal upper Section Jaws.


Heavy Duty Construction


Article  551

Cat No.

Jaw Width Jaw Depth
  Inch mm Inch mm
UDPV-1901 3 75 7/8 22
UDPV-1902 4 100 15/16 24
 UDPV- 1903 6 150 1-3/16 30

TOP



TOOL MAKERS TILLING VICE

Article  552


  Hardened and Precision Ground Steel Vise

Positive download and rapid positioning notches for free Jaw movement.


Threaded hole on both sides of stationary Jaw


Horizontal and vertical V in moveable Jaw.



Article  552

Cat No.

Jaw Width

Jaw Depth

Jaw Opening

Total Length

Inch mm Inch mm Inch mm Inch mm
TMTV-1904 1 25 3/4 19 2 50 4 100
TMTV-1905 2 50 1-1/16 30 3-1/8 80 6 150
TMTV-1906 3 75 1-3/8 35 3-3/4 95 7 175

TOP





PRECISION GRINDING VICE

Article No :- 553

Body and Jaw of solid all steel Construction and Case hardened.



Slotted sides provide multitude of clamping possibilities.



Locking Screw provided at the Vise base for adjustable positions of the moveable Jaw.




Article No :-  553

Cat No. Jaw Width Jaw Depth Jaw opening

Total Length

Weight

Inch mm Inch mm Inch mm Inch mm Inch mm
PGV-1907 2 50 1 25 3 75 6-3/8 162 3.5 1.6
PGV-1908 2-7/8 73 1-3/8 35 3-1/2 90 7-3/8 190 8 3.6

TOP





MACHINIST JACK

Article No :- 554


Made of Heavy Cast Steel.

Adjustable Screw and tilting Swivel head




Has One inch (25 mm) adjustment

A shop tool with hundreds of uses.


Article No :- 554






TOP





BEARING PULLER THREE LEGS

Article No :- 555





Manufactured from Drop Forged, Chrome Plated Steel legs.





Article No :- 555

Cat No. INCH MM
BPTL-1909 3 75
BPTL-1910 4 100
BPTL-1911 6 150
BPTL-1912 8 200
BPTL-1913 10 250

TOP
